ELECTRO/MANUAL ELEMENT MSD.M
ELECTRO/MANUAL ELEMENT MSD.M - Image 2
ELECTRO/MANUAL ELEMENT MSD.M - Image 3
ELECTRO/MANUAL DIRECTIONAL VALVES AND ACCESSORIES / Elements

ELECTRO/MANUAL ELEMENT MSD.M

TECHNICAL SHEET ELECTRO MANUAL ELEMENT MSD.M

Categories: ELECTRO/MANUAL DIRECTIONAL VALVES AND ACCESSORIES, Elements
  • Description
CODE SPOOL PART NUMBER VOLTAGE MAX FLOW P.MAX (BAR) A-B
(L/MIN)
144759
MSD6MB3BC12 12VDC 40 250 3/8
144758
MSD6MB3BC24 24VDC 40 250 3/8
144763
MSD6MC2C12 12VDC 40 250 3/8
144762
MSD6MC2C24 24VDC 40 250 3/8
144767
MSD6MC4C12 12VDC 40 250 3/8
144766
MSD6MC4C24 24VDC 40 250 3/8
